A super efficient low emission fire can be built in to existing brick surrounds or add the optional Zero-Clearance Kit to build directly into timber framing without masonry

Ares modern white.jpg

Nothing quite beats the clean lines and uncluttered look of an insert fire. No flue to look at, just an appliance on the wall surface. Clean, elegant and simple.

The Ares has all the intelligent combustion features, high output and and low fuel consumption of the freestanding models, with the benefit of discreet wall mounting.

Perfect if you have an existing open fire or log burner, the compact firebox design means there will be no trouble fitting into even the smallest open fireplaces, but don’t let the compact firebox size fool you. It can pump out a generous 14kW of heat, making it comparible to much larger rivals.

Add the extremely low emissions and high efficiency, and you’ll realise that you’re generating heat where other fires are just making smoke. Better for the environment, better for your wallet, and better for your home.

If you are building new, or renovating a home without an existing fireplace, just add in the optional Zero Clearance Kit to build your insert fire into timber framing and floors. The Ares gives maximum flexibility with minimum fuss, for the custom look you  want.

Couple all this with the large entertaining viewing window, and the ability to choose from over 100 custom colours for the front facia and you have everything you need to stylishly heat your room.


ARES Performance

Estimated Peak Output: 14kW

Average Efficiency: 67%

Average Emissions: 0.3 grams per kilogram

Emissions per Output : 22 milligrams per megajoule



dimensions

Flue Diameter: 130mm

Fire Height: 600mm

Fire Width: 615mm

Fire Depth: 465mm

Facia Height: 650mm

Facia Width: 850mm



APPROVALS

NZ MFE/ECAN approval number: 103880

Tested and compliant to the following standards:

  • AS/NZS 4012:1999 Power output and heating efficiency

  • AS/NZS 4013:1999 Flue gas emissions

  • AS/NZS 2918:2001 Safety



downloads



Price

  • $4999 Ares fire

  • $999 for 4.2m standard flue kit for existing masonry chimney*

  • $1299 for Zero Clearance Kit to build in to timber framing without masonry

  • $1599 for 4.2m Zero Clearance flue kit* (replaces standard flue kit in Zero Clearance installations)

  • $999 for Zero Clearance Base (only required for timber floor installs)

    * additional flue liners and hardware may be required for some installations. Please confirm with your Ethos dealer for total cost.




DRAFT FREE ECO-FLUE SYSTEM

DRAFT FREE
ECO-FLUE SYSTEM

HIGH OUTPUT FIREBOX

HIGH OUTPUT FIREBOX

DESIGNED FOR LOW EMISSIONS

DESIGNED FOR LOW EMISSIONS

15 YEAR FIREBOX WARRANTY

15 YEAR FIREBOX WARRANTY

OVER 100 BESPOKE COLOURS AVAILABLE

OVER 100 BESPOKE COLOURS AVAILABLE

MADE IN NEW ZEALAND

MADE IN
NEW ZEALAND
